GV-GDR2801-3F Geovision 3.6mm 30FPS @ 2MP Super Low Lux Outdoor IR Day/Night WDR Fixed Mini Dome IP Security Camera 12VDC/PoE

GV‐GDR2801 is a 2 MP outdoor mini fixed rugged IP Dome. The camera supports H.265 video codec to achieve a better compression ratio while maintaining high-quality pictures at reduced network bandwidth. GV‐GDR2801 adheres to IP67 and IK10 standards and can be powered through PoE.

Specifications

Camera

• Image Sensor - 1/2.8" progressive scan CMOS
• Picture Elements - 1920 (H) x 1080 (V)
• Minimum Illumination
  • Color - 0.008 Lux (F1.6, AGC ON)
  • IR On - 0 Lux
• Shutter Speed - Automatic / Manual (1/3 ~ 1/100000 sec)
• White Balance - Automatic, Manual
• Gain Control - Automatic, Manual
• S/N Ratio - 50 dB
• WDR Pro - Yes
• Dynamic Range - 120 dB

Lens

• Megapixel - 2MP
• Day / Night - Yes (with removeable IR-cut filter)
• Lens Type - Fixed
• Focal Length - 3.6 mm
• Maximum Aperture - F/1.6
• Mount - M12
• FOV
  • Horizontal - 89°
  • Vertical - 47.5°
  • Diagonal - 104°
• Operation
  • Focus - Fixed
  • Zoom - Fixed
  • Iris - Fixed
• IR LED
  • Quantity - 1 IR LED
  • Max. IR Distance - 30 m (100 ft)

DORI

• Lens - 3.6 mm
• Detect - 50 m (164.0 ft)
• Observe - 20 m (65.6 ft)
• Recognize - 10 m (32.8 ft)
• Identify - 5 m (16.4 ft)

Operation

• Video Compression - H.265, H.265+, H.264, H.264+, MJPEG
• Video Streaming - Triple streams from H.265, H.264 or MJPEG
• Video Resolution
  • Main Stream - 1920 x 1080 (Default), 1280 x 720
  • Sub Stream - 704 x 480, 704 x 576, 640 x 480, 640 x 360 (Default), 352 x 240, 352 x 288
  • Third Stream - 704 x 480 (Default), 704 x 576, 480 x 240, 352 x 240, 352 x 288
• Frame Rate
  • 30 fps at 1920 x 1080, 1280 x 720, 704 x 480, 640 x 480, 640 x 360, 352 x 240 (60 Hz)
  • 25 fps at 1920 x 1080, 1280 x 720, 704 x 576, 640 x 480, 640 x 360, 352 x 288 (50 Hz)
  • *The frame rate and performance may vary depending on the number of connections and data bitrates (different scenes)
• Maximum Throughput - 6 Mbps
• Maximum Streams *When the total bitrate is within the maximum throughput - 6 users
• Smart Alarm - Motion Detection, SD Card Error, SD Card Full, IP Address Conflict, Cable Disconnection, Scene Change Detection, Video Blur Detection, Abnormal Color Detection
• Video Analytics - Motion Detection, Object Abandoned / Missing Detection, Video Exception
• Image Setting - Brightness, Contrast, Hue, Saturation, Sharpness, 3D Noise Reduction, BLC, Antiflicker, White Balance, Shutter, Gain, Image Orientation (Flip, Mirror, 0°, 90°, 180°, 270° - including Corridor format)
• Audio Compression - G.711
• Audio Support - One-way Audio (external microphone required)

Deep Learning Function

• AI Analytics - Line Crossing, Region Intrusion *The two functions can only be enabled one at a time.

Network

• Interface - 10/100 Ethernet
• Protocol - 802.1x, API, DDNS, DHCP, FTP, HTTP, HTTP POST, HTTPS, IPv4, IPv6, NTP, ONVIF (Profile G, S, T), PPPoE, QoS, RTCP, RTMP, RTP, RTSP, SMTP, SNMP, UDP, UPnP

Mechanical

• Camera Angle Adjustment
  • Pan - 0° ~ 355°
  • Tilt - 0° ~ 70°
  • Rotate - 0° ~ 355°
• Connectors
  • Power - DC jack
  • Ethernet - RJ-45
  • Audio
    • Built-in microphone - No
    • External microphone required - Yes (audio jack, 3.5 mm )
    • Built-in speaker - No
    • External speaker required - No
    • * For devices with microphone or speaker, choose either the built-in or external option.
    • * If equipped with an Audio In port, it only supports microphones with power supply.
  • Digital I/O - N/A
  • Local Storage - microSD card slot (SD / SDHC / SDXC), up to 256 GB

General

• Operation Temperature - -30~ 60°C (-22 ~ 140°F)
• Humidity - 0% ~ 95% (no condensation)
• Power Source - DC 12V, 1A / PoE (IEEE 802.3af)
• Max. Power Consumption - 4W
• Dimensions - Ø 110 × 83 mm (Ø 4.3” × 3.3”)
• Weight - 0.5 kg (1.10 lb)
• Ingress Protection - IP67
• Vandal Resistance - IK10 for metal casing
• Certification - CE, FCC, RoHS, UKCA compliant

Web Interface

• Installation Management - Web-based configuration
• Maintenance - Firmware upgrade through Web Browser or GV-IP Device Utility
• Access from Web Browser - Live View, Playback, Video Recording, Image Quality, Bandwidth Control, Image, Snapshot, Digital Zoom, Text Overlay, Image Masking, Intelligent Mark
• Language - Czech, Dutch, English, French, German, Greek, Hebrew, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Romanian, Russian, Spanish, Spanish (LA), Traditional Chinese, Turkish, Ukrainian

Software Applications

• Software Supported - GV-VMS (V17.4.8 with Patch or later, V18.3.5), GV-Edge Recording Manager (V2.3.0 or later), GV-Control Center (V4.2.1 or later), GV-Recording Server (V2.1.1 with Patch or later)
• Smart Device Access - GV-Eye for iOS and Android (V3.4.1 or later)
• Live Viewing - Web Browser (Edge 120.0.2210.121, Chrome 120.0.6099.200, Firefox 121.0, Safari 11)
