GV-TVD4811 Geovision AI 4MP H.265 5x Zoom Super Low Lux WDR Pro IR Vandal Proof Dome

GV-TVD4811 is an outdoor camera designed with IK10 vandal resistance and IP66 ingress protection. GV-TVD4811 supports H.265 video codec to achieve better compression ratio while maintaining high quality pictures at reduced network bandwidths. The camera is equipped with an automatic IR-cut filter and IR LEDs for day and night surveillance. Adjustable in 3 axis (pan, tilt and rotate), it offers an entry-level surveillance solution with all the essential features and excellent image quality.

Specifications

Camera

• Image Sensor - 1/2.7" progressive scan CMOS
• Picture Elements - 2688 (H) x 1520 (V)
• Minimum Illumination
  • Color - 0.00 2Lux (F1.2, AGC ON)
  • IR On - 0 Lux
• Shutter Speed - Automatic, Manual (1 ~ 1/100000 sec)
• White Balance - Automatic, Manual
• Gain Control - Automatic, Manual
• S/N Ratio - 56 dB
• WDR Pro - Yes
• Dynamic Range - 120 dB

Lens

• Megapixel - 4 MP
• Day/Night - Yes (with removable IR-cut filter)
• Focal Length - 2.7 ~ 13.5 mm
• Lens Type - Motorized varifocal lens
• Maximum Aperture - F/1.2
• Mount - Ø 14 mm
• Horizontal FOV - 103.58° ~ 31.05°
• Operation
  • Focus - Automatic / Manual
  • Zoom - 5x Optical Zoom
  • Iris - Fixed
• IR LED Quantity - 2 IR LEDs
• Max. IR Distance - 30 m (100 ft)

Operation

• Video Compression - H.265, H.264, MJPEG
• Video Streaming - Triple streams
• Video Resolution
  • Main Stream - 2688 x 1520 (Default), 2560 x 1440, 2304 x 1296, 1920 x 1080, 1280 x 720
  • Sub Stream - 1280 x 720, 720 x 576, 640 x 480, 640 x 360 (Default)
  • Third Stream (Closed by Default) - 720 x 576, 704 x 288, 640 x 360, 352 x 288
• Frame Rate - 30 fps at 2688 x 1520, 30 fps at 2560 x 1440, 30 fps at 2304 x1296, 30 fps at 1920x 1080 (60 / 50 Hz) * The frame rate and performance may vary depending on the number of connections and data bitrates (different scenes)
• Video Analytics - Motion Detection, Tampering Alarm, Audio Detection *Tampering alarm and audio detection are only accessible through the camera's Web interface, which can be used to trigger alerts such as e-mail and FTP
• Image Setting - Brightness, Contrast, Saturation, Sharpness, Flicker-less, 3D Noise Reduction, Image Orientation (Flip, Mirror, 0°, 90°, 180°, 270°‐including Corridor format)
• Audio Compression - G.711
• Audio Support - Two‐way Audio (external speaker required)
• Digital I/O
  • Input - 1 Input, dry contact, NO / NC
  • Output - 1 Relay Output (1A 30V DC / 0.3A 125V AC)

Network

• Interface - 10 /100 Ethernet
• Protocol - 802.1x, ARP, DHCP, DDNS, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, IPv6, NTP, PPPoE, QoS, RTCP, RTP, RTSP, SMTP, SNMP, TCP, UDP, UPnP, ONVIF (Profile G, S, T)

Deep Learning Function

• AI Analytics - Intrusion, Cross Line, Enter Area, Leave Area: Human & Vehicle classification - People Flow Counting, Crowd Density Monitoring, Face Detection

Mechanical

• Camera Angle Adjustment
  • Pan - 0° ~ 356°
  • Tilt - 0° ~ 70°
  • Rotate - 0° ~ 356°
• Connectors
  • Power - 2-pin terminal block (DC 12 V, 1.25 A), PoE
  • Ethernet - RJ-45
  • Audio - 1 built-in microphone 1 In and 1 Out (4-pin terminal block pitch 2.5 mm (0.1")
  • Digital I/O - 4-pin terminal block pitch 2.5 mm (0.1")
  • Local Storage - Micro SD card slot (SD / SDHC / SDXC / UHS-I, Class 10) * UHS-II card type is not supported

Face Detection

• Environment - 100 lux
• Detectable face angle - ≤ 10° ≤ 10°, ≤ 30° ≤ 30°
• Max. number of faces - Up to 40
• Min. face image pixel requirement - 80 pixels

General

• Operating Temperature - -30°~ 55°C (-22° ~ 131°F)
• Humidity - 0 ~ 95% (no condensation)
• Power Source - 12 V DC / PoE (IEEE802.3af)
• Max. Power Consumption - 6.5 W
• Dimensions - Ø 128 x 100 mm (Ø 5.04" x 3.94")
• Weight - 0.59 kg (1.31 lb)
• Ingress Protection - IP66
• Vandal Resistance - IK10 for metal casing
• Certification - CE, FCC, LVD, RoHS compliant

Web Interface

• Installation Management - Web-based configuration
• Maintenance - Firmware upgrade through Web Browser or Utility
• Access from Web Browser - Live View, Video Recording, Change Video Quality, Bandwidth Control, Image Snapshot, Text Overlay, Image Masking
• Language - Czech, English, French, German, Hungarian, Italian, Japanese, Polish, Portuguese, Russian, Spanish, Traditional Chinese

Software Applications

• Software Supported - GV‐VMS (V17.4.6 / V18.3.2 or later), GV‐Control Center (V4.1.1 or later), GV‐Edge Recording Manager Windows Version (V2.2.7 or later), GV‐Recording Server / Video Gateway (V2.1.0 or later)
• Smart Device Access - GV-Eye for iOS and Android (V3.1.0 or later)
• Live Viewing - Bowser (IE, Edge, Chrome, Firefox, Safari), Mobile App
