IFS03B1BNWIT Illustra 2.8-12mm Motorized 30FPS @ 3MP Outdoor IR Day/Night WDR Bullet IP Security Camera 24VAC/PoE - White

Specifications

Operational

• Video Compression - H.264 / H.265 / IntelliZip / MJPEG
• Max Frame Rate - 30ips @ 3MP, 60ips @ 1080p
• ONVIF-Compliant - Profile S
• Analog Video Output - Yes
• Resolution - (2048x1536) QXGA 4:3 (1920x1080) 1080p 16:9 (1664x936) 16:9 (1280x720) 720p 16:9 (1024x576) PAL+ 16:9 (640x360) nHD 16:9 (480x360) 480 4:3 (384x288) 4:3
• Imager - 1/2.8" CMOS
• Day/Night - True D/N with ICR
• TrickleStor - Yes
• IR Distance - 25m
• Motion Detection - 3 Zones
• Blur Detection - Yes
• Privacy Zones - 9 Zones
• Alarm Input/Output - 1/1
• Audio Input/Output - 1/1
• Video Streams - Triple
• Minimum Illumination - Color 0.03 Lux, B/W 0.001 Lux
• True Wide Dynamic Range - 120dB
• Field of View (H/V) - Wide Angle 98°/71°, Telephoto35°/26°
• Aperture - F/1.4(W)~F/2.7(T)
• Lens Type - Motorized Varifocal and Focus, P-iris control, IR corrective
• Focal length - 2.8-12mm
• Supported Languages - Arabic, Czech, Chinese (Simplified), Chinese (Traditional), Danish, Dutch, English (US), French, German, Hungarian, Italian, Japanese, Korean, Polish, Portuguese (Brazilian), Russian, Spanish, Swedish, Turkish

Network

• Ethernet Interface - 10/100Base-T, RJ-45 IP66/67
• Supported Protocols - TCP/IP, IPv4, IPv6, TCP, UDP, HTTP, FTP, DHCP, WS-Discovery, DNS, DDNS, RTP, RTCP, TLS, Unicast, Multicast, NTP, SMTP, WS-Security, IEEE 802.1x,, PEAP, SSH, HTTPS, SOAP, WSAddressing, CIFS, SNMP, UPNP, RTSP, LLDP

Configuration Management

• Web Browser - Internet Explorer 8.0 or above, Firefox, Safari, Chrome
• Security - Multiple user access levels, IP address filtering, user access log, IEEE 802.1x

Onboard Storage

• Card Support - Micro SDXC Slot Up to 128GB

Simultaneous Users

• Users - 5 Simultaneous Users

Electrical

• Power Input - PoE IEEE 802.2af class 3, 24VAC
• Power Draw - 15W

Physical

• Dimensions (HxWxL) - 70x203mm
• Weight - 1.2kg (2.65lbs)
• Housing Color - White
• Operator Temperature - -40°F to 122°F
• Vandal Resistant - IK07
• Outdoor Rating - IP66, IP67, IP68

Regulatory

• Emissions - FCC Part 15 Class A; EN55032 Class A; AS/NZS CISPR 32 Class A; ICES-003/NMB-003 Class A
• Immunity - EN55024, EN50130-4
• Safety - EN60950-1; UL60950-1; IEC60950-1; CSA 22.2 No. 60950
• Environment - RoHS; WEEE

IFS03B1BNWIT Specifications PDF
