PB-100FA TAKEX 330' / 660' Double Modulated Quad Beam N/O N/C Relay 10 to 30VDC

The professional choice in outdoor protection, our Quad Beam detectors synchronise sixteen beam paths for maximum stability in severe weather conditions, perfect for long range perimeter intruder detection.

Specifications

• Product name - Photoelectric beam sensor
• Model - PB-100FA
• Detection system - Near infrared beam interruption system (4 beam simultaneous interruption)
• Infrared beam - Double modulation pulsed beams by LED
• Protection distance - outdoor 330'(100m) or less
• Max. arrival distance - 3300' (1000m)
• Response time - 50msec. to 700msec. variable (Standard : 50msec.)
• Power supply - 12V to 30V DC (non-polarity)
• Current consumption - 70mA or less at protection (max.105mA or less)
• Alarm output - Dry contact relay : NO or NC (selectable) Reset : Interruption time + off-delay (approx.1.5sec) Contact capacity : 30V (AC/DC) 1A or less
• Tamper output - Dry contact : NC Contact operation : Output when cover is detached Contact capacity : 30V (AC/DC) 0.1A or less
• Alarm LED - Red LED (receiver) lights when an alarm is initiated
• Sensitivity attenuation LED - Red LED (receiver) lights when beam reception attenuated
• Functions - Tone indicator, Alarm memory indication, Programmed AGC, Auto-gain lock, Monitor jack, Target color
• Beam adjustment - Horizontal : ±90°, Vertical : ±10°
• Ambient temperature range - -31°F to +151°F (-35°C to +66°C)
• Mounting position - Outdoor (IP55)
• Wiring - Terminals
• Weight - Transmitter : 42oz (1,200g), Receiver : 45.5oz (1,300g)
• Appearance - Resin (wine red)

PB-100FA Specifications PDF
