PB-IN100AT TAKEX 330' / 660 Intelligent Double Dual Beam, AND-OR Gated, N/O N/C Relay, 10 to 30VDC

The PB-IN-100AT is designed with high security applications in mind, where attempts to crawl through a portion of the beam result in an alarm condition.
Through CPU processing, the upper receiver selects the beam from the upper transmitter and the lower receiver selects the beam from the lower transmitter, creating an AND/OR-gated type detection system.

Specifications

• Model - PB-IN-100AT
• Detection system - Near infrared beam interruption system (TR,-RE 4 beams simultaneous interruption or upper 2 beams interruption or lower 2 beams interruption)
• Infrared beam - Double modulation pulsed beam by LED
• Protection distance - Outdoor 100m (330')or less
• Max. arrival distance - Tenfold 1000m(3300')
• Response time - Dual response time system 35-500msec. (AND gated) 100,200,300,500msec.(OR gated)
• Power supply - 12V to 30V DC(non-polarity)
• Current consumption - 57mA or less
• Alarm output - Dry contact relay output C, Reset : Interruption time+off-delay(approx. 1.5 sec.) Contact capacity : 30V AC/DC, 0.25A or less
• Environmental output
  • Dry contact relay - C
  • Contact operation - Output when weather condition gets worse
  • Contact capacity - 30V AC/DC, 0.25A or less
• Tamper output
  • Dry contact relay - N.C.
  • Contact operation - Output when transmitter or receiver cover is detached
  • Contact capacity - 30V AC/DC, 0.1A or less
• Alarm LED - Red LED(receiver)lights when an alarm is initiated
• Sensitivity attenuation LED - Red LED(receiver)lights when beam reception is attenuated
• Functions - Modulated beam frequency selection,Tone indicator, Environmental module, Beam power selection, Beam selector, Programmed AGC, Auto-gain lock function, Monitor jack, Target color
• Beam adjustment - Horizontal : ±90°, Vertical : ±10°
• Ambient temperature range - -35°C to + 66°C (-31°F to + 151°F)
• Mounting position - Outdoor
• Wiring - Terminals
• Weight - Transmitter : 1200g(42oz) Receiver : 1300g(45.5oz)
• Appearance - PC resin (wine red)

PB-IN100AT Specifications PDF
