O2VT1VN Speco Technologies 2.8-12mm Varifocal 30FPS @ 2MP Outdoor IR Day/Night DWDR Turret IP Security Camera 12VDC/PoE

Specification

• Image Sensor - Progressive scan 1/2.8" CMOS, 2MP
• Maximum Resolution - 1920 x 1080 (2MP)
• Field of View - 88° ~ 34.8° (H); 57° ~ 20° (V); 96° ~ 39.6° (D)
• Minimum Illumination - 0.009 lux @ F1.6, AGC ON, 0 lux with IR
• Video Settings - Region of Interest, Privacy masking, Brightness, Contrast, Hue, Saturation, Denoise, Antiflicker, Day/Night mode, Infrared settings, Exposure, Gain, Corridor Pattern, Image flip/mirror
• Day/Night - Smart IR up to 164' (depending on scene reflection)
• Compensation - Digital WDR, BLC, HLC
• Electronic Shutter Speed - 1 - 1/100000 sec
• DNR - 3D DNR
• Angle Adjustment - Pan 0° ~ 360°, Tilt 0° ~ 80°, Rotation 0° ~ 360°

Video

• Main Stream Resolution - 1920x1080 / 1280x720 @ 30fps
• Sub Stream Resolution - D1, CIF @ 30fps
• Third Stream Resolution - D1, CIF, 480 x 240 @ 30fps
• Compression - H.265, H.264
• Bitrate Control - VBR, CBR (64Kbps ~ 6Mbps)
• Multiple Streaming - 3 streams

Network

• Protocols - UDP, IPv4, IPv6, DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, 802.1x, UPnP, HTTP, HTTPS, QoS
• DDNS support - Speco DDNS (free of charge)
• Security - User ID & Password protection, IP/Mac address filtering, digest authentication
• User Access - Max. 3 simultaneous users, Actual number of users may vary depending on bandwidth

Audio

• Audio Compression - G.711A / G.711U

Interfaces

• Ethernet - RJ45 Jace
• Power - DC Jack
• Microphone Input - Built-in mic
• Card Slot - MicroSD, up to 128GB (not included)
• Alarm In/Out - No
• Reset - Yes

System

• PoE - Standard (IEEE 802.3af)
• Detection Events - Line crossing, region intrusion and video blurring detection
• Alarm Triggers - Motion, Detection Events, SD card error
• Image Settings - Watermark, IP address filtering, video mask, password protection

Client

• Web Browser Support - Windows (Internet Explorer 8 and up)
• PC Application - SecureGuard VMS, SecureGuard CMS
• Mobile - SecureGuard Client, Speco Blue (iPhone and Android)
• Other Platforms - Apple TV, Amazon Fire TV

Operating & Unit

• Power - PoE, 12VDC (power supply not included)
• Power Consumption - < 7.5W (max)
• Operating Temperature - -40°F ~ 140°F
• Operating Humidity - Less than 95 % (non-condensing)
• Unit Dimensions - 4.38" (ф) x 3.92" (H)
• Unit Weight - 1.47 lb
• Certifications - FCC, RoHS

O2VT1VN Specifications PDF
