PAR-C5TIR36AWL InVid Tech Paramont Series 3.6mm 20FPS @ 5MP Outdoor IR White Light D-WDR Turret HD-TVI/AHD Security Camera 12VDC

Specifications

Camera

• Image Sensor - 1 / 2.5 "CMOS
• Resolution - 5MP/4MP
• Image Size - 2560 x 1936
• Video Output - AHD / TVI /CVI
• Image System - PAL / NTSC
• Electronic Shutter - Auto
• White Light Distance - Up to 60'
• Frame Rate - 5MP@20fps/4MP@30fps
• Min. Illumination - 0 lux with IR
• Lens - 3.6 mm
• Lens Mount - M12
• S / N Ratio - ≥52dB ( AGC OFF )
• Ingress Protection - IP 67

Audio

• Microphone - Built-in Mic, Audio Over Coax (AoC) ( TVI Output Only)
• Camera audio - TVI/CVI/ Support
• Audio Sensitivity - -36db

Functions

• Function Control - OSD ( COC Control )
• Day & Night - ICR
• Digital WDR - Yes
• Digital NR - Yes, 2D DNR
• Global Exposure - Yes
• Central Exposure - YES
• AGC - No
• Auto White Balance - Yes
• BLC - Yes
• Front Light Compensation - No
• Contrast - Yes
• Sharpness - Yes
• Smart IR - No
• Image Setting - Yes
• Defect Correction - Auto
• Language - Chinese and English
• Angle Adjustment - Pan: 0°~360°; Tilt: 0°~80°; Rotation: 0°~360°

Others

• Power Supply - DC12V ( ± 10% )
• Power Consumption - IR OFF : < 1W; IR ON : <3.5W
• Working Environment - -22°F ~ 122°F (- 30 °C ~ 50 °C), 10 % ~ 90 % (relative humidity)
• Dimensions - Ф 3.7 x 3.3 in (Ф 94.6 x 82.8mm)
• Weight ( net ) - Approx. .86 lb (0.39KG)

PAR-C5TIR36AWL Specifications PDF
