P-500-H-A Dormakaba Rutherford Controls 125kHz Wiegand Proximity Reader

RCI Pyramid sets the electronic security benchmark for 125-kHz proximity readers, cards, and tags. Based upon proven contactless digital radio frequency identification (RFID) technology, Pyramid readers interface with a wide range of electronic access control systems by complying with either the legacy Wiegand or the latest bi-directional Open Supervised Device Protocol (OSDP). They offer value-add features such as MAXSecure and fleaPower, and can be ordered to support several proximity card and tag technologies. Additionally, Pyramid cards and tags are passive devices, eliminate maintenance by requiring no battery, and can be ordered to support several proximity reader technologies.

Specifications

• Technology - Proximity
• Frequency - 125 kHz
• Mounting - Metal or plastic US single-gang wall box, as well as flat surfaces
• Dimensions - 3" W x 4.6" H x 0.4" D (76 mm x 117 mm x 10 mm)
• Weight - 4 oz (113 g)
• Certifications - FCC, ICC, CE, C-Tick, UL Standard 294, ULC 60839-11-1
• IP Code - IP67
• Voltage - +5 to 16 VDC
• Current Draw - 35 mA typical, 75 mA peak @ 12 VDC
• Read Range - Up to 8 inches (202 mm)
• Cabling - 24 AWG minimum, multiconductor stranded with an overall foil shield
• Interface - Wiegand (26-bit and custom formats) or OSDP
• Operating Temperature - –31° F to 150° F (–35° C to +66° C)
• Operating Humidity - 0% to 90% relative humidity
• Color Options - Black and a white snap-on cover included standard
• Audio Tone - Beeper included standard
• Indoor & Outdoor Installation - Electronics sealed in weather- and tamper-resistant epoxy potting
• Warranty - Limited lifetime warranty
• LED - Four-state standard (red, green, amber, and off)
• Technologies Supported - P-500-H-A: Pyramid + certain HID 125-kHz Proximity protocols + certain AWID 125-kHz Proximity protocols

P-500-H-A Specifications PDF
