DWC-XSDJ08Mi Digital Watchdog 2.7~13.5mm Varifocal 30FPS @ 4K Indoor/Outdoor IR Day/Night WDR Dome IP Security Camera 12VDC/PoE - Built-in Microphone

This MEGApix Ai IP camera provides 4K resolution, placing the power of Ai deep learning at your fingertips, with object detection and people tracking. This camera features Star-Light Plus color in near-total darkness technology in a weather-resistant vandal dome housing with junction box built-in and Cold Start at -40°F/-40°C.

Specifications


• Image sensor - 4K 1/2.8" Star-Light Plus sensor
• Total pixels - 3864(H) X 2228(V)
• Active pixels - 3840(H) x 2160(V)
• Minimum scene illumination - 0.09 lux (color) / 0 lux (B/W)
• S/N ratio - 50dB
• Test monitor video output - Local video output CVBS 1.0V p-p (75Ω), 16:9 aspect ratio

Lens

• Focal length - 2.7~13.5mm, F1.4
• Lens type - Vari-focal p-iris lens with motorized zoom and auto-focus
• Field of view (HFoV/VFOV) - Horizontal: 33.1°~90.3° / Vertical: 18.9°~49°
• IR distance - 110ft range
• Optical zoom / digital zoom - 5x optical zoom

I/O

• Audio in/out, compression - 1 microphone built-in/1 output, G.711 ulaw
• Alarm input/output - 1 input/1 output
• Event trigger - Motion, network loss, temperature anomaly, illegal login, schedule, sensor

Intelligent Video Analytics

• Deep learning analytics - Deep Learning object tracking
• Analytics filters - Zones and lines, tamper, metadata, intrusion, line crossing, counting, counting lines, appear, disappear, stopped, enter, exit, direction, tailgating, dwell, logical rules

Operational

• Shutter mode - Auto, manual, anti-flicker, slow shutter
• Shutter speed - 1/15 ~ 1/32000
• Slow shutter - 1/2, 1/3, 1/5, 1/6, 1/7.5, 1/10
• Auto gain control - Auto
• Day and night - TDN, Auto, day (color), night (B/W)
• 3D Digital Noise Reduction - Smart DNR 3D-DNR
• Wide Dynamic Range (WDR) - True WDR 120dB
• White balance - Yes
• Privacy zones - 16 programmable privacy masks
• Mirror and flip - Yes
• Alarm notifications - Notifications via email notifications, FTP, alarm output and SD card recording
• Memory slot - Micro SD/SDHC/SDXC class 10 card (not included)

Network

• LAN - RJ45 (10/100Base-T)
• Video compression type - H.265, H.264, MJPEG
• Resolution
  • H.265, H.264: 3840x2160, 2592x1944, 2560x1440, 1920x1080, 1280x720, 640x480, 640x360, 352x288, 352x240
  • MJPEG: 1920x1080, 1280x720, 800x600, 768x432, 704x576, 704x480, 640x480, 640x360, 352x288, 352x240
• Frame rate - Up to 30fps at all resolutions
• Video bitrate - 100Kbps ~ 25Mbps,multi-rate for preview and recording
• Bitrate control - Multi-streaming CBR/VBR at H.265 (controllable frame rate and bandwidth)
• Streaming capability - Triple Streaming (3rd stream MJPEG only)
• IP - IPv4
• Protocol - TCP/IP, UDP, AutoIP, RTP (UDP/TCP), RTSP, NTP, HTTP, HTTPS, SSL, DNS, DDNS, DHCP, FTP, SMTP, ICMP, SNMPv1/v2/v3 (MIB-2), ONVIF
• Security - HTTPS (TLS), IP filtering, 802.1x, digest authentication
• SIP/VoIP Suppor - SIP VoIP
• ONVIF conformance - Yes
• Web viewer - OS: Windows, Mac OS, Linux, Browser: Microsoft Edge, Google Chrome, Mozilla Firefox, Safari
• Video management software - DW Spectrum IPVMS

Environmental

• Operating temperature - -40°F ~ 122°F (-40°C ~ 50°C)
• Operating humidity - 10–90% RH, (non–condensing)
• IK rating - IK10 impact-resistant
• IP rating - IP67-rated
• Other certifications - CE, FCC, UL, NDAA, TAA

Electrical

• Power requirement - DC12V, PoE IEEE 802.3af Class 3 (Adapter not included)
• Power consumption - DC: max 13.1W, 1.09A, PoE: max 15.0W, 312.5mA

Mechanical

• Material - Aluminum die-casting vandal housing, polycarbonate dome
• Dimensions - 5.74" x 5.11" (146 x 130mm)
• Weight - 3.13 lbs (1.42 kg)
• Warranty - 5 year warranty

DWC-XSDJ08Mi Specifications PDF
