DWC-PVX20WATX Digital Watchdog 4 x 2.8-8mm Motorized 30FPS @ 20MP Outdoor IR Day/Night WDR Panoramic Vandal Dome IP Security Camera 12VDC/POE

This NDAA-compliant MEGApix Flex IP camera is a 20MP multi-sensor configurable IP camera that reduces total system cost by providing four video streams with vari-focal lenses in one housing and installation. The IVA engine detects and classifies people and vehicles in real-time. The camera features Star-Light Plus color in near-total darkness technology.

Specifications


• Image sensor - 4x 1/2.8" 5.14MP CMOS
• Total pixels - 4x 2592(H) x 1944(V)
• Minimum scene illumination - 0.05 lux (color), 0.1 lux (B/W)
• Test video output - Local video output CVBS 1.0V p-p (75Ω), 4:3 aspect ratio
• S/N ratio - 50dB
• Maximum resolution - 20MP (4x 2592x1944)

Lens

• Focal length - 4x 2.8 ~ 8.0mm, F1.6
• Lens type - Vari-focal lens with motorized zoom and auto-focus
• Field of view (FoV) - 4x 51° ~ 93° HFoV/ 4x 39°~68° VFoV

I/O

• Audio in/out and compression - 1 (1.0Vms, 3K ohm) input/1 output, G.711
• Alarm in/out - 1 input/1 output

Operational

• Intelligent Video Analytics - Intrusion, line crossing, counting line, loitering, enter, exit, tamper, object removed, tailgating, direction, stopped, appear, disappear, object left, logical rules.*
• Shutter speed - 1/15 ~ 1/32000
• Slow Shutter - 1/2, 1/3, 1/5, 1/6, 1/7.5, 1/10
• Auto gain control - Auto
• Day / night - Auto, day (color), night (B/W),
• 3D digital noise reduction - Smart DNR 3D-DNR
• Wide dynamic range (WDR) - True WDR
• Wide Dynamic Range (WDR) dB - 120dB
• White balance - Auto
• Mirror and flip - Yes
• Privacy zone - 16 programmable privacy masks
• Alarm notifications - Email notifications, FTP, alarm output, SD card recording
• Memory slot - Micro SD/SDHC/SDXC class 10 card (not included)

Network

• LAN - RJ45 (10/100Base-T)
• Video compression type - H.265, H.264, MJPEG
• Resolution
  • 4x H.265, H.264 - 2592x1944, 2560x1440, 1920x1080, 704x576, 704x480, 640x480, 640x360, 352x288, 352x240
  • 4x MJPEG - 1920x1080, 1280x720, 800x600, 768x432, 704x576, 704x480, 640x480, 640x360, 352x288, 352x240
• Frame rate - Up to 30fps at all resolutions
• Video bitrate - 100Kbps ~ 10Mbps, multi-rate for preview and recording
• Bitrate control - Multistreaming CBR/VBR at H.265 (controllable frame rate and bandwidth)
• Streaming capability - Dual-stream at different rates and resolutions
• IP - IPv4
• Protocol - TCP/IP, UDP, AutoIP, RTP (UDP/TCP), RTSP, NTP, HTTP, HTTPS, SSL, DNS, DDNS, DHCP, FTP, SMTP, ICMP, SNMPv1/v2/v3 (MIB-2), ONVIF
• Security - HTTPS (TLS), IP filtering, 802.1x, digest authentication (ID/PW)
• ONVIF conformance - Yes
• Web viewer - OS: Windows, Mac OS, Linux, Browser: Internet Explorer, Google Chrome, Mozilla Firefox, Safari

Environmental

• Operating temperature - -4°F ~ 122°F (-20°C ~ 50°C)
• Operating humidity - 10–90% RH, (non–condensing)
• IP rating - IP67-rated
• IK rating - IK10 impact-resistant
• Other certifications - FCC, CE, ROHS, UL Listed, NDAA- and TAA-compliant

Electrical

• Power requirement - DC12V, PoE IEEE 802.3bt PoE+ class 5 (PoE injector included)
• Power consumption - DC12V: max 28W, PoE: max 31W

Mechanical

• Material - Aluminum vandal housing, polycarbonate dome
• Dimensions - 8.26" x 3.61" Inch (210 x 91.8 mm)
• Weight - 4.18 lbs (1.9 kg)
• Warranty - 5 year warranty

DWC-PVX20WATX Specifications PDF
