DW-BJMT5109TLX Digital Watchdog NVR 360Mbps Max Throughput with 4 Channel DW Spectrum Camera License - 9TB - Linux Ubuntu

Blackjack Tower mid-size servers are reliable and high-performance solutions for recording multiple IP cameras of any resolution at up to 480Mbps throughput. The servers are UL-listed and NDAA/TAA compliant and include Windows 10, Linux Ubuntu or Windows Server OS on a separate SSD. Hardware features include an Intel Core i3, i5 or i7 processor, up to 16GB RAM, dual network cards and local output up to 4K resolution for system configuration. The servers come preloaded with DW Spectrum IPVMS and four recording licenses, provide up to 48TB internal storage, are ONVIF conformant and come with a 5 year limited warranty.

Specifications

• Included IP licenses - 4
• Form factor - Mid-size tower
• Operating system
  • Windows 10 IoT Enterprise LTSC
  • Ubuntu Desktop 20.04.5 LTS
  • Windows Server 2019 Standard
• CPU - Intel Core i5 processor
• Memory - 16GB
• Ethernet Port - 2x 1G Ethernet
• System
  • Max video storage rate (Mbps) - 360 Mbps
• Storage
  • Maximum storage drives - 3 x 3.5 SATA HDD
  • Maximum storage - Maximum 48TB
• Video
  • Outputs - 1 x true HD, 1 x DVI, 1 x VGA for system configuration. Maximum 1 display output at a time.
  • Max output resolution - 4096x2160 (True HD), 1920x1200 (DVI-D)
  • Video card - On-board Intel Graphics
• Preloaded VMS software - DW Spectrum IPVMS
• Remote clients - Cross-platform - Windows, Linux Ubuntu and Mac
• Mobile apps - iOS and Android
• Keyboard and mouse - Included
• Power supply - 400W**
• Operating temperature - 41°F~104°F (5°C~40°C)
• Operating humidity - 20~90% RH
• Dimension (WxDxH) - 7.46" x 15.7" x 14.21" (189.52 x 398.8 x 631.02 mm)
• Other certification - UL, FCC, CE
• Warranty - 5 year limited

DW-BJMT5109TLX Specifications PDF
