FD9366-HVF2 Vivotek 2.8mm 30FPS @ 1080p Indoor/Outdoor IR Day/Night WDR Dome IP Security Camera PoE

Specifications

System Information

• Model - FD9366-HV(2.8mm)
• CPU - Multimedia SoC (System-on-Chip)
• Flash - 128MB
• RAM - 256MB

Camera Features

• Image Sensor - 1/2.9" Progressive CMOS
• Max. Resolution - 1920x1080 (2MP)
• Lens Type - Fixed-focal
• Focal Length - f = 2.8 mm
• Aperture - F1.8
• Auto-iris - Fixed-iris
• Field of View - 108° (Horizontal), 60° (Vertical), 124° (Diagonal)
• Shutter Time - 1/5 sec. to 1/32,000 sec.
• WDR Technology - WDR Pro
• Day /Night - Yes
• Removable IR-cut Filter - Yes
• IR Illuminators - Built-in IR illuminators, effective up to 20 meters with Smart IR, IR LED*2
• Minimum Illumination - 0.13 Lux @ F1.8 (Color), 0.01 Lux @ F1.8 (B/W), 0 Lux with IR illumination on
• Pan Range - ±30°
• Tilt Range - 90°
• Rotation Range - ±180°
• Pan/Tilt/Zoom Functionalities - ePTZ: 48x digital zoom (4x on IE plug-in, 12x built-in)
• On-board Storage - Slot type: MicroSD/SDHC/SDXC card slot Seamless Recording

Video

• Video Compression - H.265, H264, MJPEG
• Maximum Frame Rate - 30 fps @ 1920x1080
• Maximum Streams - 3 simultaneous streams
• S/N Ratio - 68 dB
• Dynamic Range - 120 dB
• Video Streaming - Adjustable resolution, quality and bitrate, Smart Stream III
• Image Settings - Time stamp, text overlay, flip & mirror; Configurable brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight compensation, privacy masks; Scheduled profile settings, 3DNR, video rotation, defog

Audio

• Audio Capability - One-way Audio
• Audio Compression - G.711, G.726
• Audio Interface - Built-in microphone External line in
• Effective Range - 5 meters

Network

• Users - Live viewing for up to 10 clients
• Protocols - 802.1X, ARP, CIFS/SMB, CoS, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, IPv6, NTP, PPPoE, QoS, RTSP/RTP/RTCP, SMTP, SNMP, SSL, TCP/IP, TLS, UDP, UPnP
• Interface - 10 Base-T/100 Base-TX Ethernet (RJ-45)
• ONVIF - Supported

Solution Integration

• Video Motion Detection - Five-window video motion detection
• VADP Package - Trend Micro IoT Security, Stratocast

Alarm and Event

• Alarm Triggers - Motion detection, manual trigger, digital input, periodical trigger, system boot, recording notification, camera tampering detection, audio detection, SD card life expectancy, cybersecurity events (brute force attack event, cyberattack event, quarantine event)
• Alarm Events - Event notification via digital output, email, HTTP, FTP, NAS server, SD card File upload via email, HTTP, FTP, NAS server, SD card

General

• Connectors - RJ-45 cable connector f or 10/100Mbps Network/PoE connection*1, Audio input*1, Digital input*1 (30V, 1A), Digital output*1 (12V, 50mA)
• LED Indicator - System power and status indicator
• Power Input - IEEE 802.3af PoE Class 2
• Power Consumption - Max. 5.5 W (IR on), Max. 2.8 W (IR off)
• Dimensions - 98 x 54 x 110.8 mm
• Weight - 400 g
• Safety Certifications - CE, LVD, FCC Class B, VCCI, C-Tick, UL
• Operating Temperature
  • Starting Temperature: -25°C ~ 55°C (-13°F~ 131°F)
  • Working Temperature: -25°C ~ 60°C (-13°F~ 140°F) (IR off), -25°C ~ 55°C (-13°F~ 131°F) (IR on)
• Humidity - 98%
• Warranty - 24 months

System Requirements

• Operating System - Microsoft Windows 8/7, Mac 10.12 (Chrome only )
• Web Browser - Chrome 58.0 or above, Internet Explorer 11
• Other Players - VLC: 1.1.11 or above

Included Accessories

• Others - Quick installation guide, screwdriver, alignment sticker, desiccant bag
