IPC3234EA-AHDZK-I1 Uniview Pro Series 2.8~12mm 60FPS @ 4MP Outdoor IR Day/Night WDR Dome IP Security Camera 12VDC/PoE

Specifications

Camera

• Sensor - 1/1.8" CMOS
• Min. Illumination - Colour:0.0003 lux (F1.2, AGC ON) B/W:0.0001 lux (F1.2, AGC ON) 0 lux with IR
• Day/Night - IR-cut filter with auto switch (ICR)
• Shutter - Auto/Manual, 1 to 1/100000 s
• WDR - 140 dB
• S/N - >56 dB

Lens

• Focal Length - 2.8 to 12 mm
• Optical Zoom - 4X
• Iris - F1.2
• Field of View (H) - 106.6°~ 51.3°
• Field of View (V) - 56.9°~ 28.6°
• Field of View (D) - 131.1°~ 63.1°
• Iris Type - P-iris

DORI

• DORI Distance (Detect) - 68.0m(223.0ft)~166.2m(545.2ft)
• DORI Distance (Observe) - 27.2m(89.2ft)~66.5m(218.1ft)
• DORI Distance (Recognize) - 13.6m(44.6ft)~33.2m(109.0ft)
• DORI Distance (Identify) - 6.8m(22.3ft)~16.6m(54.5ft)

Illuminator

• Illumination Distance (IR) - 131.2 ft(40 m )
• IR On/Off Control - Auto/Manual
• Wavelength - 850 nm

Video

• Frame Rate-Main Stream - 60fps @ 4MP(2688x1520)
• Video Compression - Ultra 265, H.265, H.264, MJPEG
• Frame Rate-Sub Stream - 60fps @ 2MP(1920x1080)
• Video Bit Rate - 128 Kbps to 16 Mbps
• Frame Rate-Third Stream - 60fps @ D1 (720x576)
• Privacy Mask - Up to 8 areas (8 blacks / 8 mosaics)
• ROI - Support
• Video Stream - Triple Streams
• OSD - Up to 10 OSDs


• White Balance - Auto&Outdoor&Fine Tune&Sodium Lamp&Locked&Auto2
• Digital Noise Reduction - 2D/3D DNR
• Smart IR - Support
• Flip - Normal&Flip Vertical&Flip Horizontal&180°&90°Clockwise&90°Anti-clockwise
• HLC - Support
• Defog - Digital Defog

Intelligent

• Metadata Analyse - Support human body, human face, motor vehicle and non-motor vehicle image capture and attribute collection
• Recognition - Face recognition: Max support 16 face libraries; Max supports 100000 faces in face library
• People Counting - Support People Flow Counting and Crowd Density Monitoring
• Exception Detection - Object Removed|Object Left Behind|Scene Change|Defocus Detection
• Smart Intrusion Prevention - Cross line detection, intrusion detection, enter area detection, leave area detection (support false alarm filtering and the classification of human, non-motor vehicle and vehicle)

Events

• Basic Detection - Motion Detection|Tampering Alarm|Audio Detection|Object Removed|Object Left Behind|Scene Change|Defocus Detection
• General Function - Watermark&IP Address Filtering&Access Policy&ARP Protection&RTSP Authentication&User Authentication&HTTP authentication&Alarm input&Alarm output

Audio

• Audio Compression - G.711U&G.711A
• Audio Bitrate - 128 Kbps
• Two-way Audio - Support
• Suppression - Support
• Sampling Rate - 16KHZ

Storage

• Edge Storage - Micro SD, up to 512 GB
• Network Storage - ANR, NAS (NFS)

Network

• Protocols - IGMP, RTP, SMTP, IPv4, IPv6, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, 802.1x, SNMP, QoS, SSL/TLS, SSH, TLS1.3
• Compatible Integration - ONVIF (Profile S, Profile G, Profile T, Profile M), API, SDK
• User/Host - Up to 32 users. 3 user levels: administrator, common user and operator
• Security - Password protection&Strong password&HTTPS encryption&Export operation logs&Basic and digest authentication for RTSP&Digest authentication for HTTP&TLS 1.2&WSSE and digest authentication for ONVIF
• Client - EZStation, UNV-Link, UNV-Link Pro
• Web Browser - Plug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above&Plug-in free live view: Chrome 57.0 and above, Firefox 58.0 and above, Edge 16 and above

Interface

• Audio I/O - 2 Input: impedance 1 kΩ, amplitude 2.5 V [p-p], 1 Output: impedance 600 Ω, amplitude 2.5 V [p-p]
• Alarm I/O - 3/2
• Serial Port - 1 channel RS485 interface
• Built-in Mic - Support, built-in mic*2
• Built-in Speaker - Support
• Network - 1 × RJ45 10 M/100 M/1000 M Base-TX Ethernet

Certification

• EMC - CE-EMC (EN 55032: 2015+A1:2020,EN 61000-3-3: 2013+A1: 2019,EN IEC 61000-3-2: 2019+A1: 2021,EN 55035: 2017+A11:2020) FCC (FCC CFR 47 part15 B, ANSI C63.4-2014)
• Safety - CE LVD (EN 62368-1:2014+A11:2017) UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01)
• Environment - CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
• Protection - IP67 (IEC 60529:1989+AMD1:1999+AMD2:2013) IK10 (IEC 62262:2002)

General

• Power - DC12V(±25%) , PoE+ (IEEE 802.3af)
• Power Consumption - 17W
• Power Interface - Ø5.5 mm coaxial power plug
• Dimensions - Ø 5.8” x 4.4” (Ø 148.0 x 111.4 mm) (Ø x H)
• Weight - 2.23lb (1.01kg)
• Working Environment - -22°F ~ 140°F (-30 ℃ ~ 60 ℃), Humidity: ≤ 95% RH (non-condensing)
• Surge Protection - 6 KV
• Reset Button - Support
• Heater - Support
