IPC6215SR-X5PAEW-VG Uniview Easy Series 2.7~13.5mm 5x Optical Zoom 30FPS @ 5MP Outdoor IR Day/Night WDR PTZ IP Security Camera 12VDC/PoE

Specifications

Camera

• Sensor - 1/2.7" CMOS
• Min. Illumination - Colour:0.003 lux (F1.2, AGC ON), 0 lux with IR
• Day/Night - IR-cut filter with auto switch (ICR)
• Shutter - Auto/Manual, 1 to 1/100000 s
• WDR - 120 dB
• S/N - 56dB

Lens

• Focal Length - 2.7 to 13.5 mm
• Optical Zoom - 5X
• Iris - F1.2
• Field of View (H) - 104.9° ~ 30.6°
• Field of View (V) - 55.4° ~ 17.7°
• Field of View (D) - 129.0° ~ 39.8°

DORI

• DORI Distance (Lens) - 2.7~13.5(mm)
• DORI Distance (Detect) - 70.9m~247.5m(232.5ft~812.0ft)
• DORI Distance (Observe) - 28.4m~99.0m(93.0ft~324.8ft)
• DORI Distance (Recognize) - 14.2m~49.5m(46.5ft~162.4ft)
• DORI Distance (Identify) - 7.1m~24.8m(23.3ft~81.2ft)

Illuminator

• Illumination Distance (IR) - 98.4 ft (30 m)
• Wavelength - 850 nm
• Light On/Off Control - Auto/Manual

Video

• Video Compression - Ultra 265, H.265, H.264, MJPEG
• Frame Rate - Main Stream: 30fps @ 5MP (2880x1620); Sub Stream: 30fps @ 720P (1280x720), Third Stream: 30fps @ D1 (720x576)
• Video Bit Rate - 128 Kbps to 16 Mbps
• Privacy Mask - 24 areas, up to 4 areas per scene
• U-code - Support
• ROI - Support
• Video Stream - Triple Streams
• OSD - Up to 8 OSDs


• Defog - Digital Defog
• White Balance - Auto, Outdoor, Fine Tune, Sodium Lamp, Locked, Auto2
• Digital Noise Reduction - 2D/3D DNR
• Smart IR - Support
• Flip - Normal, Flip Vertical, Flip Horizontal, 180°
• HLC - Support
• BLC - Support

Intelligent

• Exception Detection - Object Removed, Object Left Behind, Scene Change, Defocus Detection
• Smart Intrusion Prevention - Cross line detection, intrusion detection, enter area detection, leave area detection (support false alarm filtering and the classification of human, non-motor vehicle and vehicle)

Events

• Basic Detection - Motion Detection, Tampering Alarm, Audio Detection, Object Removed, Object Left Behind, Scene Change, Defocus Detection
• General Function - Watermark, IP Address Filtering, Alarm Input, Alarm Output, Access Policy, ARP Protection, RTSP Authentication, User Authentication

General

• Built-in DC12V Output - Support
• Power - DC12V(±25%), PoE+(IEEE 802.3at)
• Power Consumption - 18W
• Power Interface - Ø5.5 mm coaxial power plug
• Dimensions - Ø 5.1" x 5.7" (Ø 129 x 143.6 mm) (Ø x H)
• Weight - 780g
• Working Environment - 14 °F to 122 °F (-10 °C to 50 °C), Humidity: ≤ 95% RH (non-condensing)
• Storage Environment - 40 °F to 158 °F (-40 °C to 70 °C), Humidity: ≤ 95% RH (non-condensing)
• Surge Protection - 4 KV
• Reset Button - Support
• Material - Plastic
• Web Client Language - 22 Languages: Traditional Chinese, English, Simplified Chinese, Polish, German, Russian, French, Korean, Dutch, Czech, Portuguese (Europe), Portuguese (Brazil), Japanese, Thai, Turkish, Spanish (Latin America), Spanish (Europe), Hungarian, Italian, Vietnamese, Arabic, Slovak

Audio

• Audio Compression - G.711U, G.711A
• Audio Bitrate - 128 Kbps
• Two-way Audio - Support
• Suppression - Support
• Sampling Rate - 16 kHz

Storage

• Edge Storage - Micro SD, up to 512 GB
• Network Storage - ANR, NAS (NFS)

PTZ

• Pan Range - 350°
• Pan Speed - 0.1°/s ~ 60°/s
• Tilt Range - 0° ~ 90°
• Tilt Speed - 0.1° ~ 50°/s
• Number of Presets - 1024
• Preset Patrol - 16 patrols, up to 64 presets for each patrol
• Patrol Stay Time - 120 s to 1800 s
• Home Position - Support

Network

• Protocols - SSH, IGMP, RTP, RTCP, SMTP, IPv4, IPv6, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTSP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, 802.1x, SNMP, QoS, SSL/TLS
• Compatible Integration - ONVIF (Profile S, Profile G, Profile T), API, SDK
• User/Host - Up to 32 users. 3 user levels: administrator, common user and operator
• Security - TLS 1.3, Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF
• Client - EZStation, UNV-Link, UNV-Link Pro
• Web Browser - Plug-in required live view: IE 10+, Chrome 45+, Firefox 52+, Edge 79+

Interface

• Audio I/O - 1 Input: impedance 1 kΩ, amplitude 2.5 V [p-p], 1 Output: impedance 600 Ω, amplitude 2.5 V [p-p]
• Alarm I/O - 1/1
• Serial Port - 1 x RS485
• Built-in Mic - Support
• Built-in Speaker - Support
• WIFI - Support
• Network - 1 × RJ45 10 M/100 M Base-TX Ethernet

Certification

• EMC - CE-EMC (EN 55032:2015+A11:2020+A1:2020,EN 61000-3-3:2013+A1:2019+A2:2021,EN IEC 61000-3-2: 2019+A1: 2021, EN 50130-4:2011+A1:2014 FCC（47 CFR Part 15, Subpart B，ANSI C63.4-2014）
• Safety - UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01) CAN/CSA C22.2 NO. 62368-1-14, 2nd Ed., Issue Date:2014-12-01 EN IEC 62368-1:2020+A11:2020
• Environment - CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU)
