PRT-P8TXIR28-AI InVid Tech 2.8mm 20FPS @ 5MP Outdoor IR Day/Night WDR Miniature IP Security Camera 12VDC/PoE

Specifications

• Sensor+DSP - IMX335+NT98566
• Image Sensor - 1/2.8" Progressive scan CMOS Sensor
• Min. Illumination - 0.01lux(Color), 0lux(IR on)
• Lens Type & Focal Length - Fixed focal lens, 2.8mm@F1.6
• FOV - horizontal FOV:104°, vertical FOV:74°, diagonal FOV:130°
• IR - 2pcs Array LED
• IR Range - up to 98' (30m)
• StrobeLight - Support
• Smart IR - Support
• Shutter Time - Auto/Manual, 1/3~1/10000s
• Day/Night - IR cut filter with auto switch
• Wide Dynamic Range - WDR & DWDR
• Digital noise reduction - 2D/3D DNR

Dori Distance

• Dori Distance - Lens - 2.8mm, Detect(ft) - 208.9(63.7m), Observe(ft) - 83.7(25.5m), Recognize(ft) - 41.9(12.8m), Identify(ft) - 21.3(6.5m)

Compression Standard

• Video Compression - H.264/H.264+/H.265/H.265+
• H.264 Codec profile - Base/Main/High profile
• H.265 Codec profile - Main profile
• Video Bit Rate - 11 Kbps~8 Mbps
• Triple Streams - Support
• Audio Compression - G.711A/G.711U
• Audio Bit Rate - 64 Kbps


• Max. Image Resolution - 5MP(2880 x 1620)
• Frame Stream
  • 50Hz:20fps 2592 x 1944)
  • 25fps 4MP (2304 x 1728)
  • 25fps 3MP (2048 x 1536), 25fps 1080P (1920 x 1080)
  • 60Hz:20fps 5MP (2592 x 1944)
  • 25fps 4MP (2304 x 1728)
  • 30fps 3MP (2048 x 1536), 30fps 1080P (1920 x 1080)
• Sub Stream
  • 50Hz:25fps 720P(1280 x 720)
  • 25fps D1(704 x 576),25fps CIF(352 x 288)
  • 60Hz:30fps 720P(1280 x 720)
  • 30fps D1(704 x 480),30fps CIF(352 x 240)
• Third Stream
  • 50Hz:25fps CIF(352 x 288)
  • 60Hz:30fps CIF(352 x 240)
• Image Setting - Brightness/Contrast/Saturation/Hue/Sharpness
• BLC - Support
• HLC - Support
• ROI - Support
• Defog - Support
• Rotate - Support

Network

• Network Storage - NA
• Protocols - TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,NTP,IGMP,UPnP,SMTP,UPnP-TM,P2P,Bonjour
• Event - Smart Motion Detection/SMD (Human Classification) Video Shelter
• Perimeter Protection - Line Crossing, Area Intrusion (Human Classification)
• Analytics
  • Region Entrance
  • Region Exiting
  • Fast Moving
• System compatibility - ONVIF Profile G/S/T, CGI
• Security - User authentication, IP address filtering, Video mask
• WEB - IE, Edge, Chrome, Firefox
• Mobile Surveillance - iPhone, Android devices

Interface

• Communication interface - 1 RJ45 10M / 100M Ethernet Port
• Storage - Up to 128GB
• Mic - Support
• Reset button - Support
• Alarm I/O - NA
• Audio Sensitivity - -34±3dB

General

• Operating Conditions - -22°F ~ 140°F (-30°C ~ 60°C) Humidity 95% or less (non-condensing)
• Power Supply - DC12V ± 10%
• POE Supply - PoE (802.3af)
• Power Consumption - MAX. 7W
• Weather Proof - IP67
• Dimensions - 4 x 3.2 in (102 x 82.4 mm)
• Weight - 1 lb (450g)(0.45KG)
