IPC3624SR-ADF40KM-WP Uniview OwlView Series 4mm 25FPS @ 4MP Outdoor ColorHunter with Wise-ISP Day/Night WDR Eyeball IP Security Camera 12VDC/PoE

SKU: IPC3624SR-ADF40KM-WP

Brand: Uniview

High quality image with 4MP, 1/1.8"CMOS sensor and F1.0 large aperture lens
25/20fps @ 4MP (2688x1520), 25/20fps @ 4MP (2560x1440); 30/25fps @ 3MP (2304x1296), 30/25fps @ 2MP (1920x1080)
Ultra 265, H.265, H.264, MJPEG
Colorhunter with Wise-ISP technology ensures 24-hour full-color images
120dB true WDR technology enables clear image in strong light scene
Support 9:16 Corridor Mode
Built-in Mic
White Light, up to 30m (98ft) warm light distance
Complies with Section 889 of the NDAA

MPN: IPC3624SR-ADF40KM-WP

New to DWG? - Sign Up for immediate access to dealer pricing and benefits.

Already a DWG Customer? - Sign In to view pricing.

Product Details

Specifications

Camera

Lens

DORI

DORI Distance(Lens) - IPC3624SR-ADF40KM-WP:4.0mm
DORI Distance(Detect) - IPC3624SR-ADF40KM-WP:62.1(203.6ft)
DORI Distance(Observe) - IPC3624SR-ADF40KM-WP:24.8(81.5ft)
DORI Distance(Recognize) - IPC3624SR-ADF40KM-WP:12.4(40.7ft)
DORI Distance(Identify) - IPC3624SR-ADF40KM-WP:6.2(20.4ft)

Illuminator

Video

Video Compression - Ultra 265; H.265; H.264; MJPEG
H.264 code profile - Baseline profile, Main profile, High profile
Frame Rate - Main Stream: 25fps @ 4MP (2688x1520), 25fps @ 4MP (2560x1440), 30fps @ 3MP (2304x1296), 30fps @ 1080P (1920x1080); Sub Stream: 30fps @ 720P (1280x720), 30fps @ D1 (720x576), 30fps @ 640x360
Video Bit Rate - 128 Kbps~6144Kbps
U-code - Support
OSD - Up to 4 OSDs
Privacy Mask - Up to 4 areas
ROI - Up to 8 areas
Video stream - Dual streams


White Balance - Auto; Outdoor; Fine Tune; Sodium Lamp; Locked; Auto2
Digital noise reduction - 2D/3D DNR
Smart Illumination - Support
Flip - Normal; Flip Vertical; Flip Horizontal; 180°; 90°Clockwise; 90°Anti-clockwise
Dewarping - N/A
HLC - Support
BLC - Support
Defog - Digital Defog

Events

Basic Detection - Motion detection; Ultra motion detection; Tampering alarm; Audio detection; Cross line (based on human body detection); Intrusion (based on human body detection)
General Function - Watermark; IP Address Filtering; Access Policy; ARP Protection; RTSP Authentication; User Authentication; HTTP Authentication

Audio

Storage

Network

Protocols - IPv4; IPv6; IGMP; ICMP; ARP; TCP; UDP; DHCP; PPPoE; RTP; RTSP; RTCP; DNS; DDNS; NTP; FTP; UPnP; HTTP; HTTPS; SMTP; 802.1x; SNMP; QoS; RTMP; SSL/TLS
Compatible Integration - ONVIF (Profile S, Profile G, Profile T); API; SDK
User/Host - Up to 32 users, 2 user levels: administrator and common user
Security - Password protection; Strong password; HTTPS encryption; Export operation logs; Basic and digest authentication for RTSP; Digest authentication for HTTP; TLS 1.2; WSSE and digest authentication for ONVIF
Client - UNV-Link; UNV-Link Pro; EZStation
Web Browser - Plug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above; Plug-in free live view: Chrome 57.0 and above, Firefox 58.0 and above, Edge 16 and above

Interface

Certification

EMC - CE-EMC (EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 55035) FCC (FCC 47 CFR part15 B)
Safety - CE LVD (EN 62368-1) UL/CUL (UL 62368-1, CAN/CSA C22.2 No. 62368-1)
Environment - CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU)
Protection - IP67 (IEC 60529)

General

Power - DC 12V±25%, PoE (IEEE 802.3af) Power consumption: Max 2.8W
Power Interface - Ø 5.5mm coaxial power plug
Dimensions - Ø4.6" x 4.2" (Φ118x106mm)
Weight - 1.06lb(0.48kg)
Material - Graphene + Metal
Working Environment - -22 °F ~ 140 °F(-30 °C ~ 60 °C ), Humidity: ≤95% RH (non-condensing)
Storage Environment - -22 °F ~ 140 °F(-30 °C ~ 60 °C ), Humidity: ≤95% RH (non-condensing)
Surge protection - 4KV
Reset button - Support
Web Client Language - 13 Languages, English, Simplified Chinese, Polish, German, Russian, French, Korean, Dutch, Czech, Portuguese, Spanish, Spanish (Europe), Italian
