2GIG-TAKE100-345 2GIG 345S Wireless Hardwire Takeover Module for GC Touch and 2GIG Edge Panels

The 2GIG Wireless hardwire Takeover Module provides installers with an easy method for taking over a 12-volt prewired security alarm system and converting the existing hardwired zones into 2GIG wireless technology. The Takeover Module cannot be used to monitor Carbon Monoxide (CO) or Fire detection zones and is intended for indoor use only.

Specifications

• Frequency - 345MHz
• Input Voltage - 16.5~20VAC
• Backup Battery - Up to 12VDC 7AH
• Dimension - 3.53" (89.7mm) x 2.56" (65.0mm) x 1.22" (31.0mm)
• Weight - 3.21 oz (90.9g)
• Operating Temperature - 32°-120° F (0° to 49° C)
• Humidity - 5-95% Non-Condensing
• AC barrel connector - DC power barrel plug, type A: 5.5mm OD, 2.1 mm ID
• Input Voltage - 9-16VDC or 16.5-20VAC
• Aux Output - 10-16V, 500mA
• Supported Zones - 8 wired zones; 1 self-monitor zone
• Regulatory - ETL, FCC, Industry Canada

2GIG-TAKE100-345 Specifications PDF
