[DISCONTINUED] IP816A-HP Vivotek 4~18mm Varifocal 60fps @ 1920x1080 Indoor Day/Night Box IP Security Camera 12VDC/24VAC/PoE

Specifications

System Information

• CPU - Multimedia SoC (System-on-Chip)
• Flash - 256 MB
• RAM - 384MB

Camera Features

• Image Sensor - 1/1.9" Progressive CMOS
• Maximum Resolution - 1920x1080(2MP)
• Lens Type - Vari-focal
• Focal Length- f = 4 ~ 18 mm
• Aperture - F1.4 ~ F13
• Auto-iris - P-iris (DC-iris reserved)
• Field of View - 29° ~ 106° (Horizontal) 16° ~ 60° (Vertical) 33° ~ 130° (Diagonal)
• Shutter Time - 1/5 sec. to 1/10,000 sec.
• WDR Technology - WDR Pro
• Day/Night - Removable IR-cut filter for day & night function
• Minimum Illumination - 0.03 Lux @ F1.4 (Color) 0.001 Lux @ F1.4 (B/W)
• Pan/tilt/zoom Functionalities - ePTZ: 48x digital zoom (4x on IE plug-in, 12x built in)
• On-board Storage - SD/SDHC/SDXC card slot

Video

• Compression - H.264, MJPEG
• Maximum Frame Rate - In both compression mode 30fps @ 1920 x1080 60fps @ 1920 x1080 (In one-stream mode only)
• Maximum Streams - 2 simultaneous streams
• S/N Ratio - 50.8 dB
• Dynamic Range - Up to 100 dB
• Video Streaming - Adjustable resolution, quality and bitrate
• Image Settings - Time stamp, text overlay, flip & mirror Configurable brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight compensation, privacy masks, scheduled profile settings 3D noise reduction, EIS, video rotation, snapshot focus

Audio

• Audio Capability - Two-way audio (full duplex)
• Compression - AAC, G.711, G.726
• Interface - External microphone input Audio output

Network

• Users - Live viewing for up to 10 clients
• Protocols - IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X, UDP, ICMP
• Interface - 10Base-T/100 BaseTX Ethernet (RJ-45)
• ONVIF - Supported, specification available at www.onvif.org

Intelligent Video

• Video Motion Detection - Triple-window video motion detection

Alarm and Event

• Alarm Triggers - Video motion detection, manual trigger, digital input, periodical trigger, system boot, recording notification, camera tampering detection, audio detection
• Alarm Events - Event notification using digital output, HTTP, SMTP, FTP and NAS server, SD Card File upload via HTTP, SMTP, FTP, NAS server and SD card

General

• Smart Focus System - RBF (Remote Back Focus)
• Connectors - RJ-45 for Network/PoE connection Audio input/output BNC Video output AC 24V power input DC 12V power input Digital input*3 Digital output*1 RS485
• LED Indicator - System power and status indicator
• Power Input - DC12V/AC24V IEEE 802.3af PoE
• Power Consumption - DC Max. 9.2W AC Max. 15.4W PoE Max.12.2W
• Dimensions - 230.2 mm (D) x 70 mm (W) x 63.5 mm (H)
• Weight - Net 623g
• Safety Certifications - CE, LVD, FCC Class B, VCCI, C-Tick, UL
• Operating Temperature - Starting Temperature: 0°C ~ 60°C (32°F ~ 140°F) Working Temperature: -10°C ~ 60°C (14°F ~ 140°F)
• Warranty - 36 months

System Requirements

• Operating System - Microsoft Windows 8/7/Vista/XP/2000
• Web Browser - Mozilla Firefox 7~10 (streaming only) Internet Explorer 7/8/9/10
• Other Players - VLC: 1.1.11 or above Quicktime: 7 or above

Included Accessories

• CD - User's manual, quick installation guide, Installation Wizard 2, ST7501 32-channel recording software
• Others - Quick installation guide, warranty card, lens, camera stand, screw pack

IP816A-HP Specifications PDF
