ELK-319DG ELK Wireless Outdoor Door and Gate Sensor 319.5MHz

The ELK-319DG is a Supervised, Wireless Sensor uniquely designed for outdoor use on swing gates or doors. The sensor and magnet can be mounted using screws (included) or pipe strap style clamps or plastic wire ties. When activated the sensor transmits an open (trip) or close (restore) signal to the panel.

Specifications

• RF frequency - 319.5 MHz
• Compatibility - ELK-319 Receivers/Panels & other panels that operate on the 319.5MHz Freq. and adhere to the ITI/Interlogix protocol
• Battery type - Two (2) 3VDC lithium coin-cell (Panasonic or V arta Model CR2032)
• Operating Temp Range - -40 to 140°F (-40 to 60°C)
• Storage Temp Range - -40 to 140°F (-40 to 60°C)
• Relative Humidity - 95% non-condensing
• Dimensions
  • Sensor - 3.39" L x 1.34" W x 0.79" D
  • Magnet - 3.0" L x 0.96" W x 0.8" D

ELK-319DG Specifications PDF
