3992726 Potter AE-2 Accessory Enclosure

Features

• 18 Gage Steel Enclosure
• Accommodates up to 2 standard size stacker bracket expansion cards
• UUKL Listed for Smoke Contro

Description

The AE-2 expansion enclosure accommodates up to 2 standard size PAD100-SLCE, RLY-5, or other stacker bracket sized cards. The enclosure size is (WxHxD) 9 3/4” x 8” x 2 1/2”.

Installation

Secure the AE-2 enclosure to a suitable surface using #8 sized screws located in four of the five mounting holes provided. One expansion device can be installed in the location shown using the #6-32 sized hex nuts. An additional expander can be stacked on top of the one that is directly attached to the back box.

Technical Specifications

• Total Expansion Card Capacity - 2
• Size (WxHxD) - 9 3/4” x 8” x 2 1/2”

3992726 Specifications PDF
