[DISCONTINUED] QVP-63A-US QNAP 8 Channel NVR 396Mbps Max Throughput - No HDD

The QVP-63A QVR Pro appliance is a tower-based network surveillance server that supports real-time video/audio monitoring, high-resolution recording, and simultaneous playback from multiple IP cameras. Users can easily monitor cameras from different platforms (Windows, Mac and mobile devices), making it easier for businesses and offices to safeguard their work environments.

Specifications

• OS - QVR Pro OS (QVP)
• CPU - Intel Core i3-8100T 4-core 3.1 GHz Processor
• CPU Architecture - 64-bit x86
• System Memory - 16 GB SODIMM DDR4 (2 x 8 GB)
• Graphic Processors - Intel UHD Graphics 630
• Maximum Memory - 32 GB ( 2 x 16 GB)
• Memory Slot - 2 x SO-DIMM DDR4
• Flash Memory - 5GB (Dual boot OS protection)
• Max Local Display Live Cameras - 22ch @ All 1080p,H.264, 30FPS, 36ch @ All 720p,H.264, 30FPS
• Max Local Display Playback Cameras - 12
• Max Client Concurrent Connection - 12
• Embedded Channel - 8
• Max Channel - 36
• Max Throughput - 396 Mbps
• Drive Bay - 6 x 3.5-inch SATA 6Gb/s, 3Gb/s
• Drive Compatibility - 3.5-inch bays: 3.5-inch SATA hard disk drives, 2.5-inch SATA hard disk drives, 2.5-inch SATA solid state drives
• Hot-swappable - Yes
• M.2 SSD Slot - 2 x M.2 2280 PCIe Gen3 x2 slots
• Gigabit Ethernet Port (RJ45) - 2
• PCIe Slot - 2: Slot 1: PCIe Gen 3 x16 (CPU), Slot 2: PCIe Gen 3 x4 (PCH)
• USB 3.2 Gen 1 port - 1
• USB 3.2 Gen 2 (10Gbps) Port - 2 x Type-C USB 3.2 Gen2 5V/3A 10Gbps, 2 x Type-A USB 3.2 Gen2 5V/1A 10Gbps
• HDMI Output - 1, HDMI 2.0 (up to 3840 x 2160 @ 60Hz)
• Audio Input - 1 x 3.5mm microphone input jacks
• Audio Output - 1 x built-in speaker, 1 x 3.5mm line out jack (for amplifiers or speakers)
• Form Factor - Tower
• LED Indicators - HDD 1-6, Status, LAN, USB port, M.2 port
• LCD Display/ Button - Yes
• Buttons - Power, Reset, USB Copy
• Dimensions (HxWxD) - 7.41 x 10.41 x 11.01 inch
• Weight (Net) - 14.45 lbs
• Weight (Gross) - 17.79 lbs
• Operating temperature - 0 - 40 °C (32°F - 104°F)
• Relative Humidity - 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
• Power Supply Unit - 250W, 100-240V
• Power Consumption: HDD Sleep Mode - 26.52 W
• Power Consumption: Operating Mode, Typical - 45.6 W
• Fan - System fan: 2 x 92mm, 12VDC, CPU fan: 2 x 60mm blower fan
• Sound Level - 23.8 db(A)
• System Warning - Voice prompts or Buzzer
• Tray Locker - Yes
• File System: Internal Hard Drive - EXT4
• RAID Recovery - Yes
• Online RAID Capacity Expansion - Yes
• Online RAID Level Migration - Yes
• RAID 10+ hot spare - Yes
• RAID 10 - Yes
• RAID 6+ hot spare - Yes
• RAID 6 - Yes
• RAID 5+ Spare - Yes
• RAID 5 - Yes
• RAID 1 - Yes
• JBOD - Yes
• Single Disk - Yes
• Global Hot Spare - Yes
• Wake on LAN (WOL) - Yes
• Schedule Power On/Off (15 settings) - Yes
• Telnet & SSH logins (Admin only) - Yes
• Syslog Server & Client - Yes
• Language - English, German, French, Italian, Spanish, Polish, Swedish, Danish, Norwegian, Finnish, Russian, Japanese, Korean, Dutch, Czech, Traditional Chinese, Simplified Chinese, Turkish, Hungarian, Romanian, Thai, Portuguese/Brazil, Greek

QVP-63A-US Specifications PDF
